Ultra-Low Bake powders

GENESIS ULTRA LOW BAKE POWDER COATING (ULB)

GENESIS UBL is an Ultra-Low Bake Powder Coating system developed for use on MDF and other heath sensitive substrates. Advancements in the powder coating technology have enabled to coat on heat sensitive substrates at much lower temperature. The powder coating process has the advantages of being a one-step finishing system, not requiring successive coats or a longer time to dry. ULB powders are reclaimable, safe and environmental friendly compare to other alternatives such as liquid paints and varnishes.

Key Features Of Genesis ULB Powder Coating:

Suitable for Interior usage only.

Available in a wide range of RAL and other custom-made colours

Available in soft sandtex pattern, fine texture, and hammer tone antiques.

Environmentally friendly coating comparing with conventional liquid paints & varnishes.

One coat application process like conventional powder coating systems.

Excellent application properties, controlled particle size distribution, higher transfer efficiency, charging, and edge coverage.

Lesser surface preparations required prior to powder coating comparing with normal paints & varnishes

Significant savings in energy, time and space.

Low temperature cure permits wide range of heat sensitive substrates to be powder coated

Powder Characteristic:

Patterns	Soft Sand Texture, fine texture, hammer tone antiques
Colours	RAL & other custom-made shades as per requirement
Specific gravity	1.20 – 1.70
Particle size	Suitable for electrostatic spraying
Storage	Dry ventilation conditions below 30˚C
Shelf life	6months

Substrate:

Substrate	18mm Medium Density Fibreboard
Density	>750gm/cm3
Moisture	8-10%
Preparation	Main side requires lesser surface preparation. Edges should be sanded or treated to minimize the out gassing and pin holing. Grit paper is recommended to get the typical smooth surface.
Pre-heating	2 – 3 minutes at 130°C
Curing schedule	20 – 30 minutes at 130°C
Film Thickness	60-80 μm

Link to Technical Data Sheet
