Fusion Bonded Epoxy

GENESIS FUSION BONDED EPOXY (FBE)

GENESIS POWDER COATING offers Next Generation High Performance wide range of Fusion Bonded Epoxy coatings for Pipeline and Rebar Coating. GENESIS FBE is available in Single, Dual, and Multi-layer system to provide maximum corrosion protection for external and internal pipe coatings.

Fusion Bonded Epoxy is one of our core competency products, GENESIS as a consulting firm have provided technology services in a number of countries for manufacturing of FBE portfolio for pipe and rebar coatings with approvals from worldwide pipe coating and end user oil & gas companies.

Key Features Of Genesis Fusion Bonded Epoxy Powder Coating:

Designed for Pipeline and Rebar coatings.

Available for Single Layer, Dual Layer, and 3- Layer PE & PP Coating.

Hard durable protective coating with excellent adhesion to the steel surface.

Excellent corrosion protection & chemical resistance.

High flexibility and impact resistance.

Exceptional abrasion and gauge resistance.

Fast gel highly reactive FBE for rebar coatings.

Environmentally friendly coating.

Genesis FBE Portfolio:

Product Type	Product Code	Product Description
External Pipe Coating GENESIS 9100	GENESIS 9100FG GENESIS 9100SG GENESIS 9100LG	Faster Gel FBE for Shorter Diameter Pipelines Standard Gel FBE for Medium Diameter Pipelines Longer Gel FBE for Large Diameter Pipelines.
High Tg FBE GENESIS 9200	GENESIS 9200HT GENESIS 9201HT	Operating Service Temperature 120°C Operating Service Temperature 140°C
Dual Layer FBE GENESIS 9300	GENESIS 9300DL GENESIS 9301DL GENESIS 9302DL GENESIS 9303DL	Abrasion Resistant Overcoat (ARO) Anti-Slip Topcoat for Concrete Weight Coating UV Resistant Topcoat Extra Flexible Topcoat
Low Application Temp FBE GENESIS 9400	GENESIS 9400LAT	Low Application Temperature FBE 180°C to 200°C
FBE for Valves & Fittings GENESIS 9500	GENESIS 9500PW	For use in contact with drinking water
Internal Pipe Coating GENESIS 9600	GENESIS 9600IC GENESIS 9601IC GENESIS 9602IC	Internal Pipe Coating Standard Type Extra flow & Chemical Resistant High Service Temp Internal Coating
Rebar Coating GENESIS 9700	GENESIS 9700RC GENESIS 9701RC	Faster Gel FBE for rebar coating Flexible FBE for wire mesh coating
